Supplies
UV curable ink
Our printers run Nazdar UV-LED curable ink, from a U.S. manufacturer whose inks have been tested extensively in real-world use. High-quality ink is what protects your print heads, so this is the part of the running cost worth getting right.
Why this ink
What the ink has to do
Low viscosity
Formulated for machines that do not need the ink heated to jet at a given specification, which keeps the ink system simpler and more predictable.
Cures under UV-LED
Displays market-acceptable surface cure under UV-LED curing, which is what lets the print be dry as the head passes.
Low odor
Designed to have a low odor, which matters when the machine is running in a building that stays open.
Holds up outdoors
Long-term exterior performance with proven resistance to UV degradation and color fade.
Broad adhesion
Adheres across a range of flexible and rigid substrates, with a high attraction to vinyl and polycarbonate.
Low clogging risk
A low risk of nozzle clogging, which means smoother operation and less maintenance. High-quality ink is what protects the print heads.
Colors
The range
The ink series covers five colors. Our printers run five of them — cyan, magenta, yellow, black and white — with white printing behind CMYK or on its own to build a base on dark surfaces.
- Cyan
- Magenta
- Yellow
- Black
- White
Packaging
- 1 liter bottles
- Every color in the range
- Flush solution
- 1 liter bottles
Running cost
- Coverage
- About 2,000 sq ft from one full set of ink
- Shelf life
- About 12 months from manufacture
- Includes
- Both printing and routine printer maintenance
- Varies with
- Ink coverage, resolution settings and surface material
- Reordering
- We stock ink — call and we ship it
Coverage figures are estimates from typical use, and include ink consumed by routine maintenance as well as by printing. See our disclaimer.
Use the 260 or 270 series. Ink from outside those series voids your warranty, and it prints the wrong colors — the machines are optimized around the specific shades these inks produce, so the difference is visible rather than subtle. Buy it wherever you like; it just has to be the right ink.
Handling and safety
Treat the liquid ink
like the chemical it is
Cured ink on a wall and liquid ink in a bottle are two different things. The finished print is what your building sees; the liquid ink is a workshop chemical, and whoever handles it should know that.
Handle the liquid ink with the right protection
Uncured UV-curable ink is a chemical product. The safety data sheet calls for chemical-resistant gloves, eye protection and adequate ventilation, and warns against eating, drinking or smoking while handling it. Anyone filling tanks or flushing heads should read the sheet first.
Store it properly
Keep containers tightly closed between 65°F and 90°F (18°C to 32°C), in a dry, well-ventilated place, out of direct sunlight and away from open flames or hot surfaces. Keep out of reach of children.
Dispose of it under local rules
Contain and dispose of waste ink according to local regulations, and keep it out of drains and waterways. Empty containers go to an approved waste handling site.
Give the sheet to whoever asks for it
Facilities and environmental health teams routinely request a safety data sheet before equipment is approved. Ours is on this page — send it to them directly.
Documents
Data sheets
270 Series technical data sheet
Features, substrates, curing parameters, storage and shelf life, and the full color and part-number table. Linked from Nazdar so it is always the current revision.
260 Series technical data sheet
The same detail for machines running the 260 series.
270 Series safety data sheets
A separate current sheet for every color, published by Nazdar. Send the sheets for the colors you run to your EHS team.
260 Series safety data sheets
The same, for machines running the 260 series. Nazdar revises these, so we link their library rather than host copies that go stale.
GT3200 technical data sheet
Full printer specifications, including the ink and curing system the ink runs through.
Ask us if you need anything else for a submittal or an equipment approval — quotes, W-9, or documentation for a purchasing department.
Reordering ink?
Tell us which machine you run and we will get the right ink and flush solution out to you.
